Ricoh MP C3004 - Duplex Unit

To Next Page

To Previous Page

No. Description No. Description

8 Paper feed sensor (2nd Feed Tray)

9 Transport sensor (2nd Feed Tray)

Duplex Unit

No. Description No. Description

1 Duplex entrance motor 6 By-pass/Duplex motor

2 Right door open/close sensor 7 Duplex exit sensor

3 Duplex entrance sensor 8 By-pass paper end sensor

4 Duplex guide plate open/close sensor

5 By-pass pick-up solenoid

Component Layout

1185
