Ricoh MP C3004 - Paper Transfer Unit

Paper Transfer Unit
No. Description No. Description
1 Image Transfer Drive Roller 3 Paper Transfer Roller
2 Discharge plate
Image Transfer Unit mechanism
Drive mechanism
The Image transfer belt is driven by the "PCU motor: Black" via the gear and the ITB drive roller.
7. Detailed Descriptions
1256
