Parts Construction
The write unit comprises a housing and the following main parts:
No. Description No. Description
1 1st Mirror 5 F-theta lens
2 Dust Shield Glass 6 Soundproof Glass
3 PCU (Y,M, C, K) 7 Polygon mirror motor
4 2nd Mirror
Laser Exposure
