Overview
No. Description No. Description
1 Pick-up roller (1st paper tray) 4 Feed roller (2nd paper tray)
2 Feed roller (1st paper tray) 5 Friction roller (2nd paper tray)
3 Friction roller (1st paper tray) 6 Pick-up roller (2nd paper tray)
In this machine, an RF paper feed system is employed, and the Feed roller, Friction roller and Pick-up
roller are high durability rollers.
Feed /transport part
The paper feed tray consists of 2 stages, i.e., a main double tray and a by-pass feed tray. By using the
1st tray as a fixed tray, and the 2nd tray as a universal tray, a space-saving two-step feed is enabled.
Tray Paper size
Loading number of
sheets
Corresponding paper
thickness
1st paper tray
A4 landscape - A5
landscape
550 sheets 60 to 300g/m
2
2nd paper tray SRA3 - postcard 550 sheets 60 to 300g/m
2
Paper Feed / Transport Section
1263
