Ricoh MP C3004 - Remaining Paper Detection

Size
Knob
4 3 2 1
A3(DLT) 0 1 0 0
B4(LG)
0 0 1 1
0 1 1 1
A4 portrait 1 1 1 0
LT portrait 1 1 0 0
B5 portrait 1 0 0 0
A4 landscape(LT landscape) 0 0 0 1
B5 landscape(Exe landscape) 0 0 1 0
A5 landscape 0 1 0 1
* "0" is switch ON (PUSH), "1" is switch OFF.
* The figures in parentheses are automatic detection sizes which can be switched over in SP mode (for
SP settings, see "SP mode (paper supply transport)": SP5-181-002 to 006).
* SRA3=320×450mm(12.6"×17.7")
* Exe LEF=10.5"×7.25"
* If a pattern other than the above is detected, "Unknown Pattern" is displayed on the control panel.
Remaining paper detection
When the lift motor rotates, the remaining paper sensors 1, 2 [A] built into the motor switch ON
(unblocked) or OFF (blocked). Paper remaining in the paper feed tray is detected by the combination of
ON/OFF for the two sensors.
Paper Feed / Transport Section
