Fusing Unit
No. Description No. Description
1 Fusing pressure release sensor 8 Thermostat (edge)
2 Shield position sensor 9 Thermostat (center)
3 Thermopile (edge) 10 Non-contact thermistor (center)
4 Thermopile (center) 11 Pressure roller thermistor (center)
5 Fusing exit sensor 12 Non-contact thermistor (edge)
6 Shield drive motor 13
Pressure roller thermistors (edge, full-bleed
edge)
7 Fusing heater
Component Layout
1187
