Ricoh MP C3004 - Booklet Finisher SR3240 (D3 Bb);Finisher SR3230 (D3 BA); Accessory Check

Booklet Finisher SR3240 (D3BB)/Finisher
SR3230 (D3BA)
• To attach this optional unit, the following optional units are required.
- Bridge Unit BU3070 (D685)
- LCIT PB3170/PB3230 (D695) or Paper Feed Unit PB3160 (D693)
Accessory Check
No. Description Q’ty Remarks
1 Booklet Tray 1 Booklet Finisher SR3240 only
2 Shift Tray 2 1
3 Cushion 1
4 Joint Bracket 1
5 Relay Guide Plate 1
6 Ground Plate 1
7 Booklet Stapler Unit Fixing Cover 1 Booklet Finisher SR3240 only
8 Tray Holder 1
9 Proof Support Tray 1
10 Screws(3x6) 4
11 Screws(3x8) 1
12 Round Rivets 2
13 Screws(4x12) 4
2. Installation
234
D3BA RTB 2
Modified
