Input and Output Check
Input Check Table
Main Machine, Paper Feed Tray
5803 [INPUT Check]
5-803-001 Registration Sensor ENG [0 or 1 / 0 / 1/step]
0: paper exist
1: paper non exist
Responds to paper existence on register sensor position.
(0: paper exist, 1: paper non exist)
5-803-002 Paper Feed Sensor 1 ENG [0 or 1 / 0 / 1/step]
0: paper exist
1: paper non exist
Responds to paper existence on 1st paper feed sensor position.
(0: paper exist, 1: paper non exist)
5-803-003 Transport Sensor 1 ENG [0 or 1 / 0 / 1/step]
0: paper exist
1: paper non exist
Responds to paper existence on 1st carry sensor position.
(0: paper exist, 1: paper non exist)
5-803-004 Paper Feed Sensor 2 ENG [0 or 1 / 0 / 1/step]
0: paper exist
1: paper non exist
Responds to paper existence on 2nd paper feed sensor position.
(0: paper exist, 1: paper non exist)
Input and Output Check
559
