Image Transfer Unit

No. Description

1 Interlock switch: Front cover (LD Safety Switch)

2 Interlock switch: Duplex Unit (LD Safety Switch)

3 ITB contact and release sensor

4 ITB contact and release Motor

5 TM/ID sensor (rear)

6 TM/ID sensor (center)

7 TM/ID sensor (front)

Component Layout

1181
