Ricoh MP C3004 - Sensor Position

Md From To Distance
Paper exit Fusing roller (nip) Paper exit roller 143.6
Two-way
distribution
Fusing roller (nip) Reverse roller 143.6
Reverse roller Duplex entrance roller 1 131.3
Duplex re-supply
Duplex entrance roller 1 Duplex entrance roller 2 120.4
Duplex entrance roller 2 Duplex transport roller 1 90.9
Duplex transport roller 1 Duplex transport roller 2 83.0
Duplex transport roller 2 Duplex exit roller 27.2
Duplex exit roller Registration roller 94.7
By-pass feed
By-pass Pick-up roller By-pass Paper feed roller 30.0
By-pass Paper feed roller By-pass transport roller 24.5
By-pass transport roller First transport roller 56.0
Sensor position
Md From To Distance
First paper feed
First paper feed roller First paper feed sensor 5.0
First transport roller First transport sensor 16.8
Second paper
feed
Second paper feed roller Second paper feed sensor 5.0
Second transport roller Second transport sensor 24.3
Second transport sensor First transport sensor 88.7
Registration Registration sensor Registration roller 17.2
Paper exit Paper exit sensor Paper exit roller 17.0
Two-way
distribution
Reverse roller Reverse sensor 14.0
Duplex
Duplex entrance roller 1 Duplex entrance sensor 25.0
Duplex exit roller Duplex exit sensor 15.0
7. Detailed Descriptions
1288
