Ricoh MP C3004 - Ardf;Platen Cover Sensor

To Next Page

To Previous Page

2. Slide the scanner carriage [A] in the direction of the arrow.

3. Scanner HP Sensor [A] (Hook x 3)

ARDF/Platen Cover Sensor

1. Scanner upper cover (page 522)

4. Replacement and Adjustment

534
