Ricoh MP C3004 - Transport Roller Drive Source

Transport roller drive source
Output Drive source
Pick-up roller 1
Paper feed motor
Paper feed roller 1
Pick-up roller 2
Paper feed roller 2
First transport roller
Transport motor
Second transport roller
Registration roller Registration motor
Paper exit roller Paper exit/pressure release motor
Reverse roller Reverse motor
Duplex entrance roller 1
Duplex entrance motor
Duplex entrance roller 2
Duplex transport roller 1
By-pass feed/duplex motor
Duplex transport roller 2
Duplex exit roller
By-pass feed transport roller
By-pass pick-up roller
By-pass feed roller
By-pass Reverse roller
Image transfer drive roller (belt) Image transfer motor
Paper transfer roller
Image transfer drive roller(Follows rotation of intermediate
transfer belt)
Fusing drive roller Fusing motor
