Ricoh MP C3004 - Replacement Procedure

SP No. Classification 1 Classification 2 Value
3-335-00
3
ID.Sens TestVal:R
Vct_reg
Check:Slope
TM/ID sensor: R, value of [3]
3-335-00
4
ID.Sens TestVal:R
Vct_reg
Check:Xint
TM/ID sensor: R, value of [4]
3-335-00
5
ID.Sens TestVal:R
Vct_dif
Check:Slope
TM/ID sensor: R, value of [5]
3-335-00
6
ID.Sens TestVal:R Vct_dif Check:Xint TM/ID sensor: R, value of [6]
Replacement procedure
1. Image transfer belt unit (page 566)
2. Paper transfer roller unit (page 587)
3. Fusing unit (page 625)
4. Fusing shield position sensor unit (page 640)
5. TM/ID sensor unit [A]
• When installing the TM/ID sensor unit.
• 1. Attach the screw of the front side [B]
• 2. Attach the screw of the back side [C]
• When installed in reverse order, an SC may occur because the sensor position has shifted.
4. Replacement and Adjustment
592
