3. Input the characteristic values.
Input data for TM/ID Sensor: F into SP3-333. Input data for TM/ID sensor: C into SP3-334. Input
data for TM/ID sensor: R into SP3-335.
SP No. Classification 1 Classification 2 Value
3-333-00
1
ID.Sens TestVal:F K2: Check TM/ID sensor: F, value of [1]
3-333-00
2
ID.Sens TestVal:F Diffuse Corr TM/ID sensor: F, value of [2]
3-333-00
3
ID.Sens TestVal:F
Vct_reg
Check:Slope
TM/ID sensor: F, value of [3]
3-333-00
4
ID.Sens TestVal:F
Vct_reg
Check:Xint
TM/ID sensor: F, value of [4]
3-333-00
5
ID.Sens TestVal:F
Vct_dif
Check:Slope
TM/ID sensor: F, value of [5]
3-333-00
6
ID.Sens TestVal:F Vct_dif Check:Xint TM/ID sensor: F, value of [6]
3-334-00
1
ID.Sens TestVal:C K2: Check TM/ID sensor: C, value of [1]
3-334-00
2
ID.Sens TestVal:C Diffuse Corr TM/ID sensor: C, value of [2]
3-334-00
3
ID.Sens TestVal:C
Vct_reg
Check:Slope
TM/ID sensor: C, value of [3]
3-334-00
4
ID.Sens TestVal:C
Vct_reg
Check:Xint
TM/ID sensor: C, value of [4]
3-334-00
5
ID.Sens TestVal:C
Vct_dif
Check:Slope
TM/ID sensor: C, value of [5]
3-334-00
6
ID.Sens TestVal:C Vct_dif Check:Xint TM/ID sensor: C, value of [6]
3-335-00
1
ID.Sens TestVal:R K2: Check TM/ID sensor: R, value of [1]
3-335-00
2
ID.Sens TestVal:R Diffuse Corr TM/ID sensor: R, value of [2]
