SD Card Options

SD Card Slots

MP C4504/C5504/C6004:

MP C3004/C3504:

[A]: SD card slot 1 (option slot)

[B]: SD card slot 2 (service slot)

List of Slots Used

Optional SD cards can be set in either slot 1 or slot 2. But slot 2 is the service slot, so we recommend

that you use slot 1 to install the SD card options.

SD card options for this machine

• IPDS Unit Type M20 (page 438)

• OCR Unit Type M13 (page 443)

SD Card Options

425
