Punch Unit PU3040 (D716)

• Punching unit for the Internal Finisher SR3130 (D690).

Accessory Check

No. Description Q’ty Remarks

1 Hopper 1

2 Punch Unit Cover 1

3 Lower Front Cover 1

4 Lower Rear Cover 1

5 Holder 1

- Knob Screw - M4 1

- Tapping screws - M3x 6 3

- Decal - EMC Address 1
