Ricoh MP C3004 User Manual

Some possible problems
Garbled output:
If a string of characters (or binary data) is mistaken as a trigger and an incorrect PDL is applied, the
output will be garbled.
Incorrect printer settings:
Printer settings, for example the paper size, is incorrectly applied. This can happen when the printer
settings at the beginning of the job are initialized before a PDL switch occurred and no settings
were configured for the rest of the job.
Printer Bit Switch description
Bit Switch 2-3
This controls Auto PDL Detection by the PCL interpreter and PS interpreter.
BitSW 2-3=0 (default):
If PDL switching is applied to the job, all of the printer system, PCL interpreter and PS interpreter will
search for switching criteria (triggers).
BitSW 2-3=1:
Only the printer system will search for switching criteria (triggers). PCL/PS interpreters will not.
Bit Switch 5-3
This affects the PDL switching criteria (triggers) used by the printer system.
BitSW 5-3=0 (default):
"%%" is not used as a printer system PS trigger. "%%" will not call the PS interpreter.
BitSW 5-3=1:
"%%" is used as a printer system PS trigger.
The reason that "%%" is not included as a trigger by default, is that a string of text in the body of the job
such as the below, could result in a false positive. This would trigger a switch and result garbled output.
%%%%%%%%%%%%%%%%%%%%%%%%%%%
However some customers prefer that "%%" be included as a switching criteria. BitSW5-3=1 should be
used in such a case.
• A side effect of BitSW5-3=1 is that "userdict" will no longer be used as a PS trigger.
Bit Switch 9-0
These determine whether Auto PDL Detection for print jobs transmitted via USB/parallel will wait 10
seconds to make sure the first 2KB of the job has been sent.
Printing Features
797

Ricoh MP C3004 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Warm-up time (from sleep mode)	1 s
Time to first page (black, normal)	4.6 s
Time to first page (color, normal)	7.1 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Scan to	E-mail, FTP, Memory Card, SMB, TWAIN, USB
Scan drivers	TWAIN
Scanner type	-
Maximum scan area	297 x 432 mm
Scan speed (black)	81 ppm
Image formats supported	TIF, JPEG XR
Document formats supported	PDF
Control type	Touch
Product color	Black, Grey
Display diagonal	10.1 \
Market positioning	Business
Internal memory	2048 MB
Processor family	Intel Atom®
Processor frequency	1330 MHz
Compatible memory cards	SD
Maximum internal memory	4092 MB
Internal storage capacity	250 GB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	2200 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	220 sheets
Custom media width	90 - 320 mm
Custom media length	148 - 1260 mm
Duplex media weight	52 - 256 g/m²
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Letterhead, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 300 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5
Duplex media weight (imperial)	14 - 142 lbs
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 166 lbs
Auto Document Feeder (ADF) media weight	40 - 128 g/m²
Auto Document Feeder (ADF) media weight (imperial)	11 - 34 lbs
Maximum duty cycle	- pages per month
Recommended duty cycle	0 - 20000 pages per month
Page description languages	PDF, PCL 5c, PCL 6
AC input voltage	120 - 127 V
AC input frequency	60 Hz
Power consumption (sleep)	0.83 W
Power consumption (average operating)	1.584 W
Energy Star Typical Electricity Consumption (TEC)	1.2 kWh/week
Sustainability certificates	ENERGY STAR
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, SNMPv3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows RT 8.1, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Faxing	Color faxing
Fax memory	320 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	2 sec/page
Fax speed dialing (max numbers)	2000

Weight and Dimensions

Depth	738 mm
Width	668 mm
Height	1206 mm
Weight	101000 g
