Ricoh MP C3004 - Bin Tray BN3110 (D3 CQ); Accessory Check

To Next Page

To Previous Page

1 Bin Tray BN3110 (D3CQ)

Accessory Check

No. Description Q’ty Remarks

1 Tray 1

2 1 Bin Tray Unit 1

3 Tray support bar 1

4 Harness 1

5 Gear 1

6 Screw: M3 x 8 2

7 Harness cover 1

8 Paper support guide 1 Not used for this machine

1 Bin Tray BN3110 (D3CQ)

203
