PostScript3 Unit Type M19 (D3BD-05, -06,

-07)

Accessories

No. Description Q’ty

1 SD Card 1

2 PS3 Decal 1

Installation procedure

• When installing more than one SD card, perform the merge operation (page 427 "SD Card Appli

Move").

1. Remove the SD card slot covers [A] [B].

MP C4504/C5504/C6004:

PostScript3 Unit Type M19 (D3BD-05, -06, -07)

433
