MP C3004/3504

No. Description No. Description

1 PCU: Black / Image Transfer Motor 2 Development Solenoid

The PCU: Black / Image Transfer Motor is also used for image transfer unit and waste toner bottle. This

is switched by the development solenoid.

Component Layout

1191
