Target Part/SP No.: Paper Feed Sensor (1st Feed Tray) / SP5-803-002 (Paper Feed Sensor 1)
Cause verification Problem Judgement
Execute an INPUT check when there is no paper at the position of the
referenced sensor.
0: Paper detected
Execute an INPUT check when there is paper at the position of the
referenced sensor.
1: Paper not detected
Solution:
• Clean the sensor.
• Reconnect the connector.
• Replace the sensor.
• Replace the Paper Transport IOB.
• Replace the harness.
Target Part/SP No.:Paper Feed Motor / SP5-804-016 (Feed Motor:CW:Standard Speed)
Cause verification Problem Judgement
Turn the referenced motor OFF with OUTPUT check Drive sound heard
Turn the referenced motor ON with OUTPUT check Drive sound not heard
Solution:
• Reconnect the connector.
• Replace the motor.
• Replace the Paper Transport IOB.
• Replace the harness.
Checking paper status, pick-up roller, feed roller, and friction roller for 1st feed tray
Check the paper position (Check whether or not the
leading edge of the paper, side paper guide, and end
paper guide are positioned according to the manual.)
• Check the paper orientation.
• Turn the paper in the feed tray
upside down.
Check if the paper has reached the maximum stackable
limit of the side paper guide.
Reduce the paper to below the stackable
limit.
Check if the sheets are stuck to each other due to edge
roughness, coating, stain, or temperature.
Fan the paper.
Troubleshooting for Transport/Paper Feeding of the Machine
