Solution:
• Clean the sensor.
• Reconnect the connector.
• Replace the sensor.
• Replace the Paper Transport IOB.
• Replace the harness.
Target Part/SP No.:Tray Set Switch (2nd Feed Tray) / SP 5-803-020 (Tray 2: Set Sensor)
Cause verification Problem Judgement
Manually press the referenced switch (Done after removing paper
feed tray 2 from the machine.)
1: Not set
Pull out the paper feed tray 2 from the machine. 0: Set
Solution:
• Clean the sensor.
• Reconnect the connector.
• Replace the sensor.
• Replace the Paper Transport IOB.
• Replace the harness.
Target Part/SP No.:Paper Feed Sensor (2nd Feed Tray) / SP5-803-004 (Paper Feed Sensor 2)
Cause verification Problem Judgement
Execute an INPUT check when there is no paper at the position of
the referenced sensor.
0: Paper detected
Execute an INPUT check when there is paper at the position of the
referenced sensor.
1: Paper not detected
Solution:
• Clean the sensor.
• Reconnect the connector.
• Replace the sensor.
• Replace the Paper Transport IOB.
• Replace the harness.
Troubleshooting for Transport/Paper Feeding of the Machine
1107
