Electric system

No. Part name

1 Development intake fan (page 711)

3 Paper exit cooling fan (page 712)

4 Fusing exhaust fan (page 713)

5 Deodorization filter (page 710)

6 Ozone exhaust fan (page 712)

7 Drive cooling fan (page 714)

8 Toner supply cooling fan (page 715)

9 Main exhaust fan (page 715)

10 Ozone filter/Dust filter (page 709)

11 Controller Box Cooling Fan (page 718)

Exterior Cover/Air Flows (Fan Control)
