Electric system

No. Part name

1 Development intake fan

3 Paper exit cooling fan

4 Fusing exhaust fan

5 Deodorization filter

6 Ozone exhaust fan

7 Toner supply cooling fan

8 Ozone filter/Dust filter

9 Controller Box Cooling Fan

7. Detailed Descriptions

1318
