3. Put the harness of the heater [A] for the optional paper feed unit through the hole at the
inner rear frame, and then attach it ( x1).
4. Remove the securing brackets [A] of Paper Feed Unit PB3150.
5. Remove the rear cover [A] of Paper Feed Unit PB3150.
6. Remove the bracket [A] on the bottom of the main unit ( x1).
The removed bracket can be discarded.
2. Installation
136
