Engine SP Tables-6
SP6-XXX (Peripherals)
6006 [ADF Adjustment]
6-006-001 Side-to-Side Regist: Front *ENG [-3 to 3 / 0 / 0.1mm/step]
6-006-002 Side-to-Side Regist: Rear *ENG [-3 to 3 / 0 / 0.1mm/step]
6-006-003
Leading Edge Registration:
Front
*ENG
[-5 to 5 / 0 / 0.1mm/step]
6-006-004
Leading Edge Registration:
Rear
*ENG
[-5 to 5 / 0 / 0.1mm/step]
6-006-005 Buckle: Duplex Front *ENG [-5 to 5 / 0 / 0.1mm/step]
6-006-006 Buckle: Duplex Rear *ENG [-5 to 5 / 0 / 0.1mm/step]
6-006-007 Rear Edge Erase Front *ENG [-10 to 10 / -2.3 / 0.1mm/step]
6-006-008 Rear Edge Erase Rear *ENG [-10 to 10 / -2.3 / 0.1mm/step]
6-006-010 L-Edge Regist (1-Pass): Front *ENG [-5 to 5 / 0 / 0.1mm/step]
6-006-011 L-Edge Regist (1-Pass): Rear *ENG [-5 to 5 / 0 / 0.1mm/step]
6-006-012 1st Buckle (1-Pass) *ENG [-3 to 3 / 0 / 0.1mm/step]
6-006-013 2nd Buckle (1-Pass) *ENG [-2 to 3 / 0 / 0.1mm/step]
6007 [ADF INPUT Check]
See page 559 "Input and Output Check"
6008 [ADF OUTPUT Check]
See page 559 "Input and Output Check"
6009 [ADF FreeRun]
6-009-001 Free Run Simplex Motion ENG [0 or 1 / 0 / 1/step]
Engine SP Tables-6
