6-011-014 Exit Sensor ENG [0 or 1 / 0 / 1/step]
Gets sensor information from ADF. Gives 1 when there is a paper at sensor area.
6-011-015 Feed Cover Sensor ENG [0 or 1 / 0 / 1/step]
Gets sensor information from ADF. Gives 1 when cover is open.
6-011-016 Lift Up Sensor ENG [0 or 1 / 0 / 1/step]
Gets sensor information from ADF. Gives 1 when lift up.
6-011-018 Pick-Up Roller HP Sensor ENG [0 or 1 / 0 / 1/step]
Gets sensor information from ADF. Gives 1 when pick up roller is not in home position.
6-011-021 Bottom Plate HP Sensor ENG [0 or 1 / 0 / 1/step]
Gets sensor information from ADF. Gives 1 when bottom plate is not in home position.
6-011-022 Bottom Plate Position Sensor ENG [0 or 1 / 0 / 1/step]
Gets sensor information from ADF. Gives 1 when pick up roller is not in the correct
position.
6-011-023 Original Length 4 (LT/A4 Tail
Sensor)
ENG [0 or 1 / 0 / 1/step]
Gets sensor information from ADF. Gives 1 when there is a paper at sensor area.
Finisher
6123 [INPUT Check: 2K/3K FIN]
6-123-001 Entrance Sensor ENG [0 or 1 / 0 / 1/step]
Gets information of specified sensor. Displays signal level of sensor as it is.
6-123-002 Horizontal Transport Sensor ENG [0 or 1 / 0 / 1/step]
Gets information of specified sensor. Displays signal level of sensor as it is.
6-123-003 Switchback Transport Sensor ENG [0 or 1 / 0 / 1/step]
Gets information of specified sensor. Displays signal level of sensor as it is.
3. Engine SP Mode Tables
576
