5-804-016 Feed Motor:CW:Standard
Speed
ENG [0 or 1 / 0 / 1/step]
5-804-017 Feed Motor:CW:Middle
Speed
ENG
5-804-018 Feed Motor:CW:Low Speed ENG
5-804-022 Feed Motor:CCW:Standard
Speed
ENG
5-804-023 Feed Motor:CCW:Middle
Speed
ENG
5-804-024 Feed Motor:CCW:Low
Speed
ENG
5804 [OUTPUT Check]
Moves vertical carry motor.
5-804-028 Bypass V-Transport
Motor:CW:Std Speed
ENG [0 or 1 / 0 / 1/step]
5-804-029 Bypass V-Transport
Motor:CW:Middle Speed
ENG
5-804-030 Bypass V-Transport
Motor:CW:Low Speed
ENG
5804 [OUTPUT Check]
5-804-034 Bypass V-Transport
Motor:Position Hold
ENG [0 or 1 / 0 / 1/step]
Holds position of vertical carry motor.
5-804-037 Exit Motor: CW: Fusing
Pressure Release
ENG [0 or 1 / 0 / 1/step]
Moves fusing dis-pressure.
* If driving this motor while attaching the fusing unit, be sure to stop it less than 5
seconds. Otherwise, the unit might be damaged.
5804 [OUTPUT Check]
Moves paper exit motor.
Input and Output Check
