5-804-065 Duplex Entrance

Motor:CW:Standard Speed

ENG [0 or 1 / 0 / 1/step]

5-804-066 Duplex Entrance

Motor:CW:Middle Speed

ENG

5-804-067 Duplex Entrance

Motor:CW:Low Speed

ENG

5-804-068 Duplex Entrance Motor:

Normal Speed: Duplex

ENG

5-804-069 Duplex Entrance Motor:

Low Speed: Duplex

ENG

5804 [OUTPUT Check]

Moves duplex bypass motor.

5-804-071 Duplex Bypass

Motor:CW:Standard Speed

ENG [0 or 1 / 0 / 1/step]

5-804-072 Duplex Bypass

Motor:CW:Middle Speed

ENG

5-804-073 Duplex Bypass

Motor:CW:Low Speed

ENG

5-804-074 Duplex Bypass Motor: CW:

Normal Speed: Dup

ENG

5-804-075 Duplex Bypass Motor: CW:

Low Speed: Duplex

ENG

5-804-077 Duplex Bypass

Motor:CCW:Standard

Speed

ENG

5-804-078 Duplex Bypass

Motor:CCW:Middle Speed

ENG

5-804-079 Duplex Bypass

Motor:CCW:Low Speed

ENG

5804 [OUTPUT Check]

Input and Output Check
