6-162-016 Untitled ENG [0 or 1 / 0 / 1/step]
6-162-017 Punch Motor ENG [0 or 1 / 0 / 1/step]
6-162-018 Punch Move Motor ENG [0 or 1 / 0 / 1/step]
6-162-019 S-to-S Registration
Detection Move Motor
ENG [0 or 1 / 0 / 1/step]
6-162-020 Stack Transport Motor:
Upper
ENG [0 or 1 / 0 / 1/step]
6-162-021 Stck Trns Uppr Prss Rls/
Stndrd Fence Rtrct M
ENG [0 or 1 / 0 / 1/step]
6-162-022 Stack Lower Pressure
Release Motor
ENG [0 or 1 / 0 / 1/step]
6162 [FIN (1K FIN) OUTPUT Check]
Continuously runs specified motor for operation test.
6-162-023 Folder Transport Motor ENG [0 or 1 / 0 / 1/step]
6162 [FIN (1K FIN) OUTPUT Check]
Drives specified motor for a certain period of time to test operation.
6-162-024 TE Stopper Motor ENG [0 or 1 / 0 / 1/step]
6-162-025 Folder Blade Motor ENG [0 or 1 / 0 / 1/step]
6162 [FIN (1K FIN) OUTPUT Check]
Lights all guide LED.
6-162-026 Navigation LED (All) ENG [0 or 1 / 0 / 1/step]
6185 [Output Check: NoStplBindFIN]
6-185-001 Transport Motor ENG [0 or 1 / 0 / 1/step]
Checks the transport motor’s movement of non staple finisher.
6-185-002 Shift Motor ENG [0 or 1 / 0 / 1/step]
Checks the shift motor’s movement of non staple finisher.
3. Engine SP Mode Tables
608
