15. Slide the stamp holder [A] out and install the stamp cartridge in it, if necessary.
• After the stamp installation, be sure to slide the holder in correctly. Make sure to slide it in
thoroughly until the reference marks on the holder and exterior cover are aligned. If it is not
mounted correctly, the machine detects a J001 paper jam.
2. Installation
188
