3. Attach the studs provided with the option on the helmholtz silencer (Stud ×4).

4. Attach the counter interface board [A].

5. Connect the harness of the MFP to the upper connector (white/13 pin) [A].

• Do not use the harness that is provided with the accessories for the interface cable.

2. Installation

390
