-18

Machine Code Product Name DF CPM

D238 GSA MP C3004SPG

SPDF 3100 Std.

FC: 30cpm/BW: 30cpm

D239 GSA MP C3504SPG FC: 35cpm/BW: 35cpm

D240 GSA MP C4504SPG FC: 45cpm/BW: 45cpm

D242 GSA MP C6004SPG FC: 60cpm/BW: 60cpm

-19

Machine Code Product Name DF CPM

D238 MP C3004SP

ARDF 3090 Std.

FC: 30cpm/BW: 30cpm

D239 MP C3504SP FC: 35cpm/BW: 35cpm

D240 MP C4504SP

SPDF 3100 Std.

FC: 45cpm/BW: 45cpm

D242 MP C6004SP FC: 60cpm/BW: 60cpm

-21

Machine Code Product Name DF CPM

D238 MP C3004SP None FC: 30cpm/BW: 30cpm

D239 MP C3504SP FC: 35cpm/BW: 35cpm

D240 MP C4504SP FC: 45cpm/BW: 45cpm

D242 MP C6004SP SPDF 3100 Std. FC: 60cpm/BW: 60cpm

-22

Machine Code Product Name DF CPM

D238 DSc1230

None

FC: 30cpm/BW: 30cpm

D240 DSc1245 FC: 45cpm/BW: 45cpm
