5. PCDU

[A] Y ×1, ×1, ×1

[B] M ×1, ×1, ×1

[C] C ×1, ×1, ×1

[D] K ×1, ×1, ×1

• When attaching the PCDU, clamp the harness so that the bind [A] comes above the clamp.
