Patient data
ARCADIS Varic
SPR2-310.620.30.02.02 25
of 60
The Patient Browser window 0
When you call up the Patient Browser, the Patient Browser window is dis-
played and placed into the foreground.
The window is subdivided into various processing areas and therefore provides
you with access to your data in a clearly laid out manner.
(1) Menu and tool bar
(2) Navigation area
(3) Information box
(4) Content area
(5) Status bar
Tool bar You can edit the data you have selected using the menus or the icon buttons on
the tool bar.
Navigation area The lower data levels for the selected databases, patients, studies and series are
displayed graphically in the navigation area.
Information box In the information box you can see brief information about the patient and study
selected.
Content area The content area contains a list of the studies or procedure steps for the patient
selected in the navigation area. If you select the lower data levels, you can see
which series or procedure steps are stored for a study and which images or
action items are stored for a series or procedure step.
