Siemens ARCADIS Varic - Labels; C-Arm System

Operator Manual
22
of 34 SPR2-310.620.30.02.02
Technical Data
Labels 0
C-arm system 0
The labels shown below are attached permanently to the following sub-assem-
blies.
(1) I.I. unit
(2) Image intensifier
(3) I.I. grid
(4) SIREPHOS X-ray tube housing
(5) X-ray system (control); system identification label
(6) Tube assembly collimator
(7) Single-tank laser targeting device (optional)
(8) Support arm
(9) I.I. laser aimer
(10) Cassette holder (option)
Equipotential bonding
3rd edition 7.2.4
Read Operator Manual
(1)
(2)
(3)
(7)
(6)
(4)
(8)
(10)
(5)
(9)
