Operator Manual
46
of 52 SPR2-310.620.30.02.02
Examination
Configuration 0
The generation, printing and exporting of reports is configured in the Structured
Reporting dialog. Depending on the type of report (LithoReport or Radiation
Summary Report), you have different configuration possibilities.
Calling up the configuration window 0
You can call up the configuration window from the syngo Configuration Panel.
◆ Select Options > Configuration from the main menu.
◆ Double-click the Structured Reporting button.
–The Structured Reporting dialog is displayed.
Configuring the
LithoReport
To configure a LithoReport, you perform settings on the following cards:
❏ Parameter sets: Here you define the contents of different selection lists.
❏ Stone locations: Here you define the position indications for nephroliths
(gallstones etc.).
❏ Options: Here you perform the presettings for LithoReport printing.
To Next Page
