Image Processing
ARCADIS Varic
SPR2-310.620.30.02.02 35
of 78
Windowing using the mouse 0
You can assign new window values to images using the mouse.
Pay attention to the scope.
â—† Click on an image segment with the center mouse button and move the
mouse holding the button down.
– The mouse cursor disappears.
â—† Drag the mouse up or down.
– The window center (brightness) is changed.
Or
â—† Move the mouse right/left.
– The window width (contrast) is changed.
– As soon as you release the mouse button, the new window values are also
applied to all the other selected images or the selected scope of action.
The changed window values are displayed immediately in the image (interactive
windowing).
Brightness -
(center +)
Brightness +
(center -)
Contrast –
(width +)
Contrast +
(width –)
