Options
ARCADIS Varic
SPR2-310.620.30.02.02 17
of 24
I.I. laser aimer (option) 0
Laser specifications
❏ Laser class: 1M (IEC 60825-1:1993+A1:1997+A2:2001)
❏ Wave length: 635 Nm
❏ Color: red
❏ Max. power: 0.8 mW (+/10%)
Integrated I.I. laser aimer 0
To project the target crosshairs, two Class 1M lasers are used whose exit win-
dows are arranged offset by 90° in the holding ring for the I.I. grid:
Removable image intensifier laser light localizer 0
The I.I. laser light localizer is attached to the image intensifier unit using a retain-
ing strap:
◆ To activate the I.I. laser light localizer, press one of the two keys.
– The I.I. laser light localizer is activated.
◆ To deactivate it, press one of the two keys again or wait approx.1 min. until it
switches off automatically.
Warning
Laser radiation
Danger of eye injury!
◆ Do not view the beam using optical instruments (laser class 1M).
