Operator Manual
20
of 24 SPR2-310.620.30.02.02
Options
Cassette exposure 0
The ARCADIS Varic does not have automatic exposure control for cassette tech-
nique.
Cassette holder
The cassette holder may only be attached in one specific position at the image
intensifier. In this position the centering pins on the cassette holder (1) must sit
in the recesses in the plastic ring of the image intensifier.
Follow the instructions given on the warning label affixed to the cassette holder!
Cassette size Only 24 cm x 30 cm (10 inches x 12 inches).
1
2
3
Caution
The cassette holder is not sufficiently shielded from leaking radiation.
Risk to operating personnel and patient
â—† Do not stand behind the cassette holder in the direction of the radiation.
