Siemens ARCADIS Varic Operator's Manual

Operator Manual
16
of 78 SPR2-310.620.30.02.02
Image Processing
Subdividing the image area 0
With the division of the image area, you define the number and size of the seg-
ments in the image area.
Switch to a large format display with just a few images on the screen if you want
to see diagnostic details. Select a small format display to obtain an overview.
◆ Select a layout in the View menu.
Or
◆ Select a layout with the buttons on the View subtask card.
– When you select a new layout, the division of the image area is changed,
but the sequence of the images displayed remains the same.

Siemens ARCADIS Varic Specifications

General

Type	Mobile C-arm
Image Intensifier	9-inch or 12-inch
DICOM Compatibility	Yes
Frame Rate	Up to 30 fps
Focal Spot Size	0.3/0.6 mm
Monitor	Dual 18-inch TFT LCD monitors
