Examination
ARCADIS Varic
SPR2-310.620.30.02.02 23
of 52
Roadmap 0
In the first step of the Roadmap examination, the max. fill image is created as a
mask from a normal subtraction (phase A and phase B). You can use the existing
subtraction mask if you have already performed a subtraction angiography during
the current examination. In that case, the first step of the Roadmap examination
is not required.
A previously created subtraction mask can also be used if you have switched to
a different operating mode (such as DR). The subtraction mask symbol (display
to show existing subtraction mask) will remain active.
In the second step, the display of the vessel into which the catheter is to be
positioned is superimposed by current fluoroscopic images (phase C).
Generating a new fill
If there is no suitable subtraction mask (e.g. from a previous subtraction angiog-
raphy), you have to generate a new fill image.
Prerequisites: The patient to be examined has been registered.
â—† Make the necessary settings for the examination.
(→ Page 11)
â—† Set the Roadmap mode in the Examination task card or by pressing the cor-
responding key on the control panel.
– The symbol for the current operating mode, Roadmap, is displayed.
– The LED of the RoadMap key lights up.
â—† Release radiation with the hand switch or with the assigned footswitch.
– The live image is displayed on the left monitor.
â—† Inject the contrast medium as soon as the syringe symbol appears on the
screen.
Keep the radiation release button pressed until the vessel is filled with contrast
medium.
â—† Let go of the radiation release button.
– Radiation is stopped.
