Image Processing
ARCADIS Varic
SPR2-310.620.30.02.02 5
of 78
Image area 0
In the image area, the images that you have loaded into the Viewing task card
are displayed.
Display of the image
area
The image area is subdivided into segments. One image is displayed in each seg-
ment. Depending on the division of the screen and the number of images loaded,
you can only see some of the images. The remaining images are in the back-
ground. The last loaded image is displayed in the top left segment.
You can choose between the following layouts:
❏ Small-format layout
An overview of many images at the same time is displayed.
❏ Large-format layout
Only a few images are displayed on one page in a format large enough to
show all details.
Image, text and
graphic objects
In the Viewing task card, medical images can be supplemented with graphic
elements or texts.
Control area 0
In the control area, you will find the tools you need to select image material,
arrange the screen display and process images.
Here you can also control data exchange with other parts of the program and
access other applications.
The display of the control area and the availability of functions depends on the
selected display mode.
Display modes 0
The Basic display mode is designed for standard post-processing steps. The con-
trol area is limited to the essential functions.
The Extended display mode contains additional functions for detailed evaluations
and post-processing.
You can switch between the two display modes at any time with the
Basic/Extended button.
