Configuration
ARCADIS Varic
SPR2-310.620.30.02.02 21
of 24
Changing parameters â—† Select the required new parameters from the selection lists.
â—† Click this button.
– Your changes are applied to the ARCADIS Varic system.
– The configuration dialog remains open for further entries.
â—† Continue configuring the next operating mode on the corresponding tab card.
—or—
â—† Click this button.
– The dialog box closes.
The LUT Data tab card 0
The specified Look-up-Tables (LUTs) are valid for those operating modes of the
current examination set which generate/display native images.
If the SUB/Roadmap option is enabled, additional LUTs (look-up tables) can be
selected for those operating modes of the current examination set that generate/
display subtracted images.
Up to 4 LUT values can be activated. You can switch between them using the
LUT keys for monitor A and monitor B on the C-arm system.
