Measuring distances and angles 0
You can measure and evaluate distances and angles in images, if the
2D Measurement option is available.
Drawing a distance line, measuring the distance 0
Using a distance line, you can measure the distance between two points in an
image.
When measuring distances near the edge of the image, take into account that the
I.I. distortion will result in measurement errors. These depend on the I.I. format.
With full format the error of measurement is comparatively large whereas it is
considerably smaller with an increasing zoom factor.
Drawing a distance
line
◆ Call up Tools > Distance.
—or—
◆ Click on the Distance button of the Tools subtask card.
– The cursor changes shape.
◆ Place the mouse cursor on the starting point of the distance line.
◆ Hold the left mouse button down and drag out a line.
◆ Release the mouse button to finish the line.
