Technical Data
X-ray tube unit 0
Max. output and focuses in operating modes 0
SIREPHOS single-tank
high-frequency generator
Inverter frequency 15 kHz up to 26 kHz
Inherent filtration 3 mm Al eq. + 0.1 mm Cu
X-ray tube Stationary anode, focal spot nominal value 0.6
CFC/SUB/
ROADMAP/PFC
(≤ 2 f/s)
PFC (> 2 f/s) DR (k = 1) DR (k > 1)
Tube voltage 40 – 110 kV 40 – 110 kV 40 – 110 kV 40 – 110 kV
Tube current 0.2 – 15.2 mA 1 – 23 mA 1 – 23 mA 0.2 – 14.3 mA
Exposure time n.a. 7 – 24 ms 7 – 42 ms n.a.
Pulsed output n.a. max. 2.3 kW max. 1.8 kW n.a.
Mean power max. 550 W
max. 1000 W for
CFC and PFC
high contrast
max. 550 W
max. 1000 W for
PFC high contrast
n.a. n.a.
