Options
ARCADIS Varic
SPR2-310.620.30.02.02 11
of 24
Text-based entry keys 0
Control panel, English text (option) 0
Most of the keys on the C-arm system control panel are labelled with text rather
than symbols.
(1) Operating mode selection
(2) Selection of image parameters (high-contrast fluoroscopy, image quality,
image display), automatic dose regulation OFF (ADR Stop)
(3) Collimator setting
(4) Radiation indicator, X-ray tube assembly temperature
(5) Image postprocessing
(6) Image selection, storing and printing
(7) Lift/lower C-arm
(8) Image rotation
(9) Display exposure time, reset exposure time (confirm warning tone)
(10) Select and display X-ray parameters, select laser light localizer, single tank
(option)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)(10)
(7)
