Siemens ARCADIS Varic Operator's Manual

Operator Manual
10
of 52 SPR2-310.620.30.02.02
Examination
Image area 0
In the image area the fluoroscopic images are displayed during and after expo-
sure. Additional information may be shown as image text, depending on the con-
figuration (see → Register 6: Image Processing, Page 78).
(1) Information on kV and mA
(2) Window value and LUT information
Live images As soon as the exposure (i.e. radiation) starts, the current fluoroscopic images
(live images) are displayed in the image area of the Examination task card.
Last Image Hold (LIH) The last fluoro image (Last Image Hold) is displayed in the Examination task card
as soon as the exposure is terminated.
(1) (2)

Siemens ARCADIS Varic Specifications

General

Type	Mobile C-arm
Image Intensifier	9-inch or 12-inch
DICOM Compatibility	Yes
Frame Rate	Up to 30 fps
Focal Spot Size	0.3/0.6 mm
Monitor	Dual 18-inch TFT LCD monitors
