Operator Manual
24
of 78 SPR2-310.620.30.02.02
Image Processing
Scrolling from series to series 0
You cannot only scroll image by image or page by page, but also by entire series
if you have loaded more than one series of a study into the Viewing task card.
It depends on the selected display which images are subsequently displayed in
the image area. In image stripe display, for instance, the first image of the series
to which you have scrolled is displayed in the first image segment. In stack dis-
play, the series stacks move to the left or right by one position, and up or down
line by line.
◆ Call up Scroll > Series Next or Scroll > Series Previous in the main menu.
Or
◆ Press the Series- or Series+ key on the symbol keypad.
Or
◆ Scroll with the image scroll symbols in the scroll bar.
Scrolling from study to study 0
The image area of the Viewing task card contains all the images of the loaded
studies and series, provided they all fit on one screen page.
As soon as you have loaded the images, the images of the first study are dis-
played starting at the top left.
◆ Select Scroll > Next Study or Scroll > Previous Study in the main menu.
– You page forward or backward by one study.
Or
◆ Scroll to the next or previous study using the Study- or Study+ key.
Sequence for displaying images 0
Sometimes the sequence of displaying images changes. However, a highly
improbable combination of settings must have been selected:
❏ Images of a patient that were created using the Save button are loaded into
the Viewing task card. Afterward, these are saved as "New series".
❏ After saving these images as a new series, the sequence of the images and
also the continuous numbering in the image text could have changed.
