Siemens ARCADIS Varic Operator's Manual

Operator Manual
36
of 60 SPR2-310.620.30.02.02
Patient data
Correcting Data 0
Patient and examination data can be changed and added to in the Correct dialog
box.
Calling up the dialog
window Correct
◆ Select the patient, study, series or images that you want to correct in the nav-
igation or content area of the Patient Browser.
◆ Call up Edit > Correct.
—or—
◆ Click on the icon button on the tool bar.
–The Correct dialog box opens.
(1) Name and number of selected data
(2) Entry form for correction data, divided in data areas
(3) Entry cards for details of the individual data

Siemens ARCADIS Varic Specifications

General

Type	Mobile C-arm
Image Intensifier	9-inch or 12-inch
DICOM Compatibility	Yes
Frame Rate	Up to 30 fps
Focal Spot Size	0.3/0.6 mm
Monitor	Dual 18-inch TFT LCD monitors
